Jabsco, 2" Clutch Pump, Electro-Magnetic, Self-Priming Impeller Pump, 18330 Series
Mfr: Jabsco
$1,484.23 to $1,529.93
DESCRIPTION
Jabsco, 2" Clutch Pump, Electro-Magnetic, Self-Priming Impeller Pump, 18330 Series.
MARINE: Engine cooling, Pumping bilges, Washdowns, Circulating water in bait tanks, Utility dockside pump.
INDUSTRIAL: Circulating and transferring, Velocitymixing, Return spill, Sump drainage, Chemicals, Pharmaceuticals, Soap, Liquors, Ink, Dyes, Alcohol, Tanning Liquors, Glycerine, Brine, etc.
FARMING: Pumping water for stock, Pumping water from shallow wells and cisterns.
PUBLIC UTILITIES AND MUNICIPALITIES: Under the hood mounting on service trucks for dewatering and draining meter boxes, manholes, excavations, and truck installation under hood for emergency pumping.
Product Specs and Installation Instructions and Diagrams
- Flow rate: Nominal 83 gpm (314 Liters/min) at 1,750 rpm
- Self-priming from dry up to 7.8' (2.4m)
- Constructed from marine quality bronze and stainless steel for ruggedness and reliability
- Inexpensive to buy and operate, easy to service and maintain
- Will tolerate abrasive wear
- Handles hard and soft solids without clogging
- Can pump in either direction
- Will not airlock
- Body: Bronze
- Impeller: Neoprene or Nitrile
- Wearplate: Replaceable
- Shaft: Stainless steel
- Shaft Seal: Carbon/ceramic mechanical type
- Bearings: Twin single row, ball type
- Port Type: 2" NPT
- Clutch Type: Electro-magnetic 12 or 24 volt
- Pulley: 7" (178mm) 'A' or 'B' section
- Weight: 29 lb (13.2kg)
MARINE: Engine cooling, Pumping bilges, Washdowns, Circulating water in bait tanks, Utility dockside pump.
INDUSTRIAL: Circulating and transferring, Velocitymixing, Return spill, Sump drainage, Chemicals, Pharmaceuticals, Soap, Liquors, Ink, Dyes, Alcohol, Tanning Liquors, Glycerine, Brine, etc.
FARMING: Pumping water for stock, Pumping water from shallow wells and cisterns.
PUBLIC UTILITIES AND MUNICIPALITIES: Under the hood mounting on service trucks for dewatering and draining meter boxes, manholes, excavations, and truck installation under hood for emergency pumping.
Product Specs and Installation Instructions and Diagrams
SPECS
Item #
MPN
Volts
Pulley
Belt
Clutch Current
Jabsco, Self-Prime Magnetic Clutch Impeller Pump, 2", 2 A Belts, 24 volt, 18330-0001
Item #:531910-24Volt
MPN:18330-0001
Volts: 24 volt
Pulley: Double Belt
Belt: 2) Type "A"
Clutch Current: 2 amp
Jabsco, Self-Prime Magnetic Clutch Impeller Pump, 2", 2 Belt, 12 volt, 18330-0000
Item #:531910-12Volt
MPN:18330-0000
Volts: 12 volt
Pulley: Double Belt
Belt: 2) Type "A"
Clutch Current: 4 amp
