ACR Electronics RCL-85 LED Searchlight

The all-new RCL-85 LED searchlight was designed for the boater who wants to ditch the hassle of halogen searchlights but still wants their affordability. With an impressive 240,000 candelas using 6 High Flux (30W) LEDs, you have visibility over ½ of a nautical mile to light the way to your destination. The simple installation only requires running your 12 to 24-volt power to the searchlight, all operations are completely wireless.

The RCL-85 LED’s sleek design makes it an attractive and cost-effective choice for small to medium-sized recreational powerboats as well as light commercial vessels. This searchlight comes with a wireless handheld remote to rotate the light 350 degrees. With an 8-degree beam angle, the light can tilt an impressive 90 degrees to make lighting draw bridges, buoys, and docks a breeze. Need to get some assistance, use the Strobe function to signal for help. The RCL-85 is weather resistant with the electronics located in the IP68 water-resistant light head instead of the base for increased protection. The ASA housing and lens are sealed against the elements for years of trouble-free operation.

Key Features:

• 6 High Flux LEDs (OSRAM)
• 240,000 Candela, Max Beam Distance 3,215 Feet (980 m)
• Wireless Handheld Remote (Included)
• 350^o Rotation and 90^o Tilt (45^o up and 45^o down from home position)
• 2 Amps (12V) to 1.1 Amps (24V)
• Efficient, long-life LED’s - 50,000 operating hours
• UV & Weather Resistant
• Simple Installation (12-24V Power Connection Only)

ACR Product Number	PN 1956 (White) / PN 1957 (Black)
Size	5.5 x 6.3 x 7.7” (14 x 16 x 19.5 cm)
Weight	3.1 lbs (1.34 kg) (searchlight only)
Material	Acrylonitrile Styrene Acrylate (ASA) Housing for improved weather resistance
Color	White or Black
Operation	Remote-controlled wireless handheld remote (included) / 433.92 MHz
Peak Beam Candle Power	240,000
Beam Maximum Distance	3,215 Feet (980 Meters)
Beam Pattern / Angle	Spot / 8o
Elevation Angle	90° (45° up and 45° down from home position)
Rotation	350°
Rotation Speed	18o per second
Elevation Speed	13° per second
Lamp	LED 30W (OSRAM x 6) / 50,000 hour life
IP Rating	IP 56 (Housing) / IP 68 (LED Module)
Accessories	Wireless Dash Mount Remote (PN 9635 - sold separately) Standard Remote Control (PN 9636 - included)
Footprint Diameter	5.03” x 4.09” (12.8 x 10.4 cm)
Power Requirements	12 or 24 V DC
Warranty	2 Years
Patents	9,212,813 & 9,890,923
